HINA
HINA-BALCONY016
| Availability: | |
|---|---|
| Quantity: | |
Balcony solar panel system is integrated plug-and-play home solar power system. It consists of core components such as a balcony bracket, a micro-inverter (or small inverter), and solar panels. Designed for ordinary users, it integrates the core components needed for solar power generation, emphasizing DIY installation and adaptability to various scenarios. It is highly favored in markets such as Europe and is commonly used for small-scale solar power generation on balconies, gardens, wall and flat roofs.
Integrated Design
Easy Installation and Operation
Diverse Scenarios
Safe, Reliable, and Easy to Monitor
ITEM | 1-Panel System | 2-Panel System | 4-Panel System |
lnstallation Typc | Balcony / Wall / Fat | ||
Solar Panel Power | 620W | 450W*2 | 620W*4 |
Array Mode | Horizontal | ||
Power of Micro-inverter | 500W | 800w | 2000W |
Rated Output Voltage | 220V-240V/50Hz | ||
Material of Bracket | ZAM Steel + Spray | ||
Adjustable Angle | 10-30 degrees | ||
8-Hour Total Power Output | 3.47~4.46kWh | 5.04~6.48kWh | 13.89~17.86kWh |
